Dimensions
442.4 x 325 x 43.7 mm (17.4 x 12.8 x 1.7")
Weight
Without Rackmount Brackets: 5.11 kg (11.27 lb)
With Rackmount Brackets: 5.20 kg (11.46 lb)
Enclosure Material
SGCC Steel
Hardware
Processor
Quad-Core ARM® Cortex®-A57 at 1.7 GHz
System Memory
4 GB
On-Board Flash Storage
8 GB
Max. Power Consumption
100W
Max. Power Budget for Drives
75W
Power Method
(1) Universal AC input, 100-240VAC, 2A Max, 50/60 Hz
(1) USP-RPS DC input, 11.5VDC, 10.43A
Power Supply
AC/DC, Internal, 120W
Networking Interfaces
(1) 10/100/1000 Mbps RJ45 Ethernet
(1) 1/10 Gbps SFP+ Ethernet
Management Interface
Ethernet In-Band Management
ESD/EMP Protection
Air: + 12kV, Contact: + 8kV
Operating Temperature
-5 to 40 C (23 to 104 F)
Operating Humidity
5 - 95% Noncondensing
Certifications
FCC, CE, IC
LEDs
System
(1) Power, Blue/White
Flashing White: Bootup in Progress
Flashing Blue/White: Firmware Upgrading
Steady White: Factory Defaults, Awaiting Adoption
Steady Blue: Device is Adopted
Ethernet
Green: 1000 Mbps, Amber: 10/100 Mbps
SFP+
White: 10 Gbps, Green: 1 Gbps
HDD
Amber: Disk Error, White: Disk Detected
RPS
Blue: Ready
