Ubiquiti UBB-XG Building Bridge XG Access Point Call For Best Price in Dubai, UAE, Oman, Iran, Africa
Ubiquiti UBB-XG Building Bridge XG Access Point Call For Best Price in Dubai, UAE, Oman, Iran, Africa
Product Code:
Availability:
Availability:
Ubiquiti UBB-XG
Out Of Stock
Out Of Stock
A 60 GHz wireless point-to-point bridge with 10G SFP+ uplink for maximum performance.
#1: 500 m (1,640 ft) maximum range
#2: 60 GHz & 5 GHz dual-radio redundancy
#3: (1) 10G SFP+ and (1) GbE PoE++ port
#4: Powered using PoE++
#5: Built-in LED alignment indicators
#6: Sold as 2-pack
Mechanical
Dimensions 191.8 x 59 mm (7.6 x 2.3")
Enclosure material Aluminum alloy, UV-resistant polycarbonate
Mount material Stainless steel
Pole mount diameter 1-2.5" on pipe outer diameter
Weatherproofing IPX6
Hardware
Networking interface (1) GbE RJ45 port
(1) 1/10G SFP+ port
Management interface Ethernet
Bluetooth
Power method PoE++
Passive PoE:
4-pairs (1, 2+; 3, 6-) (4, 5+; 7, 8-)
2-pairs (4, 5+; 7, 8-)
Power supply UniFi PoE switch
48V, 0.65A Gigabit PoE adapter (included)
Supported voltage range 48V DC + 10%
Max. power consumption 31.2W
Max. TX power
2.4 GHz –
5 GHz 23 dBm
6 GHz –
16 dBm (60 GHz)
MIMO
2.4 GHz –
5 GHz 2 x 2
6 GHz –
Max. data rate
2.4 GHz –
5 GHz 866.6 Mbps (BW80)
6 GHz –
6 Gbps (60 GHz)
Antenna gain
2.4 GHz –
5 GHz 14 dBi
6 GHz –
21 dBi (60 GHz)
Maximum range 500 m (1,640 ft)
LEDs R/G/B
Button Factory-reset
Mounting 60G precision alignment pole mount (Included)
Ambient operating temperature -40 to 55 C (-40 to 131 F)
Ambient operating humidity 5 to 95% noncondensing
Certifications FCC, IC, CE, terragraph
Software
WiFi standards 802.11a/b/g/n/ac
Wireless security WPA2 AES (Always On)
Operating modes PtP
VLAN Management VLAN only
RF
Operating frequency 57 to 66 GHz
Dependent on regional regulations.
Channel bandwidth 2,160/4,320 MHz (Channel Bonding Enabled)
Operating channels 58,320/59,400/60,480/61,560/62,640/63,720/64,800 MHz
Dependent on regional regulations.
Backup RF
Operating frequency U-NII-1: 5,150 - 5,250 MHz
US/CA U-NII-2A: 5,250 - 5,350 MHz
U-NII-2C: 5,470 - 5,725 MHz
U-NII-3: 5,725 - 5,850 MHz
Worldwide 5,150 - 5,725 MHz
Dependent on regional regulations.
Channel bandwidth 20/40/80 MHz
Supported Data Rates (Mbps) 802.11a 6, 9, 12, 18, 24, 36, 48, 54 Mbps
802.11b 1, 2, 5.5, 11 Mbps
802.11g 6, 9, 12, 18, 24, 36, 48, 54 Mbps
802.11n 6.5 Mbps to 300 Mbps (MCS0 - MCS15, HT 20/40))
802.11ac 6.5 Mbps to 867 Mbps (MCS0 - MCS9 NSS1/2, VHT 20/40/80)
