Ubiquiti U7-Outdoor Wi-Fi 7 Wall Access Point - UniFi 7 Ourdoor Call For Best Price in Dubai, UAE, Oman, Iran, Africa
Ubiquiti U7-Outdoor Wi-Fi 7 Wall Access Point - UniFi 7 Ourdoor Call For Best Price in Dubai, UAE, Oman, Iran, Africa
Product Code:
Availability:
Availability:
Ubiquiti U7-Outdoor
Out Of Stock
Out Of Stock
All-weather WiFi 7 AP with 4 spatial streams, an integrated directional super antenna, and versatile mounting options.
#1: WiFi 7
#2: 4 spatial streams
#3: 465 m² (5,000 ft²) open space coverage with the integrated directional super antenna
#4: Software-adjustable antenna beamwidth for balanced coverage with the included omni antennas
#5: 200+ connected devices
#6: Powered using PoE+
#7: 2.5 GbE uplink
#8: Versatile wall and pole mounting
#9: Weatherproof (outdoor exposed)
Technical Specifications
Dimensions 170 x 208 x 54.5 mm (6.7 x 8.2 x 2.1")
Weight 1.2 kg (2.6 lb)
Enclosure material UV-stabilized polycarbonate, aluminum alloy
Mount material Polycarbonate, SGCC steel
Pole mount diameter 25–60 mm (1–2.36") on pipe outer diameter
Wind survivability 74.6 N at 200 km/h (16.8 lbf at 125 mph)
Weatherproofing IPX6
Hardware
Networking interface (1) 1/2.5 GbE RJ45 port
Management interface Ethernet
Power method PoE+
Power supply UniFi PoE Switch
Supported voltage range 42.5—57V DC
Max. power consumption 19W
Max. TX power
2.4 GHz 23 dBm
5 GHz 26 dBm
6 GHz -
MIMO
2.4 GHz 2 x 2 (DL/UL MU-MIMO)
5 GHz 2 x 2 (DL/UL MU-MIMO)
6 GHz -
Throughput rate
2.4 GHz 688 Mbps (BW40)
5 GHz 4.3 Gbps (BW240)
6 GHz -
Antenna gain
2.4 GHz Directional internal: 8 dBi/External omni: 3 dBi
5 GHz Directional internal: 12.5 dBi/External omni: 4 dBi
6 GHz -
Antenna beamwidth
2.4 GHz 90 Degreee
5 GHz 45 Degree
6 GHz -
Antennas (1) Directional internal antenna
(2) External omni antennas
(2) RP-SMA connectors for external antenna
LEDs (1) Power: white/blue
(4) Mesh signal: blue
Button Factory reset
Mounting Wall, ceiling, pole (Included)
Ambient operating temperature -30 to 60° C (-22 to 140° F)
Ambient operating humidity 5 to 95% noncondensing
Certifications CE, FCC, IC
Software
WiFi standards 802.11a/b/g/n/ac/ax/be (WiFi 6, WiFi 7)
Wireless security WPA-PSK, WPA-Enterprise (WPA/WPA2/WPA3/PPSK)
BSSID 8 per radio
VLAN 802.1Q
Advanced QoS Per-user rate limiting
Guest traffic isolation Supported
Concurrent clients 200+
Supported Data Rates
802.11a 6, 9, 12, 18, 24, 36, 48, 54 Mbps
802.11b 1, 2, 5.5, 11 Mbps
802.11g 6, 9, 12, 18, 24, 36, 48, 54 Mbps
802.11n 6.5 Mbps to 300 Mbps (MCS0 - MCS15, HT 20/40)
802.11ac 6.5 Mbps to 1.7 Gbps (MCS0 - MCS9 NSS1/2, VHT 20/40/80/160)
802.11ax (WiFi 6) 7.3 Mbps to 2.4 Gbps (MCS0 - MCS11 NSS1/2, HE 20/40/80/160)
802.11be (WiFi 7) 7.3 Mbps to 4.3 Gbps (MCS0 - MCS13 NSS1/2, EHT 20/40/80/160/240)
