Ubiquiti U-Cable-C6-CMP UniFi Indoor Cable CMP
Ubiquiti U-Cable-C6-CMP UniFi Indoor Cable CMP
Product Code:
Availability:
Availability:
Ubiquiti U-Cable-C6-CMP
Out Of Stock
Out Of Stock
Category 6 Ethernet cable for high-speed deployments located in environments that require plenum-rated cabling
The U-Cable-C6-CMP is a Category 6 UTP cable that supports speeds up to 1Gbps with its 23 AWG solid copper, twisted pair conductor. The conductor's small diameter, combined with the cable's anti-crosstalk divider, isolates and protects signals from interference. The U-Cable-C6 is also a CMP cable with a fire-resistant jacket that ensures full fire prevention, which is especially critical in plenum spaces where air is circulated to facilitate building HVAC. Category 6 Ethernet connectors are recommended to accommodate the conductor's size and optimize its performance.
Features:
- Category 6 Unshielded Twisted Pair (UTP) cable
- Communications Multipurpose Cable, Plenum (CMP)-rated, fire-resistant jacket
- 1,000 ft (305 m)
- 23 AWG solid copper conductor pair
- Anti-crosstalk divider
- For 1000BASE-T Ethernet applications
Mechanical
Box Dimensions 474 x 346 x 458 mm (18.7 x 13.6 x 18")
Box Weight 14.75 kg (32.52 lb)
Cable Length 305 m (1000 ft)
Cable Color White
Cable Type Category 6
Shielding Type UTP
Flame Rating CMP
Conductor Wire Gauge 23 AWG
Conductor Type Solid Bare Copper
Jacket Material Low Smoke Flame Retardant PVC
Jacket Diameter 5.6 ± 0.2 mm
Bend Radius Min. 22.4 mm
Pulling Tension Max. 110 N
Storage Temperature -20 to 75°C (-4 to 167°F)
Installation Temperature 0 to 60°C (32 to 140°F)
Operation Temperature -20 to 60°C (-4 to 60°F)
Anti-Crosstalk Divider Yes
Ripcord Yes
Data Rate 10/100/1000 Base-T
Reference Bandwith Up to 600 MHz
